Work Height 22.75m
Platform Height 20.75m
Horizontal Outreach 17.4m
A - Stowed Length 10.36m
B - Stowed Width 2.49m
C - Stowed Height 2.78m
D - Platform Length 2.44m
E - Platform Width 0.91m
F - Wheelbase 2.52m
Tread 2.48m
G - Ground Clearance 0.42m
Platform Capacity (Unrestricted/Restricted) 300/454kg
Drive Speed (Stowed) 6.0km/h
Gradeability 45% (24°）45%(24°）
Turning Radius (Inside) 2.4m
Turning Radius (Outside) 5.4m
Turntable Swing 360°continuous
Platform Rotation ±90°
Tail Swing 1.45m
Jib (Range of Articulation) 135°（﹣60°~75°）
Max. Wind Speed 12.5m/s
