Work Height 28.20m
Platform Height 26.20m
Horizontal Outreach 23.31m
A - Stowed Length 12.50m
B - Stowed Width 2.49m
C - Stowed Height 2.80m
D - Platform Length 2.44m
E - Platform Width 0.91m
F - Wheelbase 3.05m
Tread 2.48m
G - Ground Clearance 0.40m
Platform Capacity (Unrestricted/Restricted) 300/454kg
Drive Speed (Stowed) 5.5km/h
Gradeability 45%(24°）
Turning Radius (Inside) 3.6m
Turning Radius (Outside) 6.8m
Turntable Swing 360°continuous
Platform Rotation ±90°
Tail Swing 1.60m
Jib (Range of Articulation) 130°（﹣55°~75°）
Max. Wind Speed 12.5m/s
