Work Height 40.2m
Platform Height 38.2m
Horizontal Outreach 25m
A - Stowed Length 12.26m
B - Stowed Width 2.49m
C - Stowed Height 3m
D - Platform Length 2.44m
E - Platform Width 0.91m
F - Wheelbase 3.81m
Tread 2.49/3.87m
G - Ground Clearance 0.41m
Platform Capacity (Unrestricted/Restricted) 300/454kg
Drive Speed (Stowed) 5km/h
Gradeability 45%(24°）
Turning Radius (Inside) 3.3/7.7m
Turning Radius (Outside) 8.2/10.8m
Turntable Swing 360° continuous
Platform Rotation ±90°
Tail Swing 1.48m
Jib (Range of Articulation) 135°（﹣60°~75°）
Max. Wind Speed 12.5m/s
