Work Height 58.8m
Platform Height 56.8m
Horizontal Outreach 25.5m
A - Stowed Length 14.4m
B - Stowed Width 2.5m
C - Stowed Height 3.06m
D - Platform Length 2.44m
E - Platform Width 0.91m
F - Wheelbase 5.357/4.69m
Tread 2.5/5.15m
G - Ground Clearance 0.40m
Platform Capacity (Unrestricted/Restricted) 300/454kg
Drive Speed (Stowed) 4.5km/h
Gradeability 45%(24°）
Turning Radius (Inside) 6.79/2.57m
Turning Radius (Outside) 8.43/6.39m
Turntable Swing 360° continuous
Platform Rotation ±90°
Tail Swing 2.16m
Jib (Range of Articulation) 125°（﹣55°~70°）
Max. Wind Speed 12.5m/s
