Rear Wheel 8.25-15-14PR
Front Wheel 8.25-15-14PR
Overall Dimension(L×H×W) 3516×2000×2500
Weight 7980
Rated capacity 5000Kg
Load centre 600
Lifting height 3000
Free lifting height 203
Tilting angle 6°/12°
Turning radius 3415
Front overhang 610
Tread 335
Wheelbase 2340
Fork spread(Min./Max.) -
Working aisle width with pallet(Ast) -
Service weight -
Operating pressure for attachment 20MPa
