Work Height 21.38m
Platform Height 19.38m
Horizontal Outreach 12.3m
Up and Over Height 8.25m
A - Stowed Length 8.82m
B - Stowed Width 2.46m
C - Stowed Height 2.52m
D - Platform Length 2.44/1.83m
E - Platform Width 0.91/0.76m
F - Wheelbase 2.52m
G - Ground Clearance 0.42m
Platform Capacity 250kg/360kg
Drive Speed 6.1km/h
Gradeability 45%(24°）
Axles Oscillation 0.2m
Turning Radius (Inside) 2.51m
Turning Radius (Outside) 5.47m
Turntable Swing 360° continuous
Platform Rotation ±90°
H-Tail Swing 0.4m
Max. Working Slope -
Max. Wind Speed 12.5m/s
