Work Height 33.85m
Platform Height 31.85m
Horizontal Outreach 21.17m
Up and Over Height 14.52m
A - Stowed Length 12.6m
B - Stowed Width 2.49m
C - Stowed Height 3.1m
D - Platform Length 2.44m
E - Platform Width 0.91m
F - Wheelbase 3.81m
G - Ground Clearance 0.42m
Platform Capacity 250kg
Drive Speed 5.2km/h
Gradeability 45%
Axles Oscillation 0.2m
Turning Radius (Inside) 7.7/3.3m
Turning Radius (Outside) 10.8/8.2m
Turntable Swing 360° continuous
Platform Rotation ±90°
H-Tail Swing 0
Max. Working Slope -
Max. Wind Speed 12.5m/s
