Work Height 26.23m
Platform Height 24.23m
Horizontal Outreach 18.9m
Up and Over Height 9.29m
A - Stowed Length 11.27m
B - Stowed Width 2.49m
C - Stowed Height 2.82m
D - Platform Length 2.44m
E - Platform Width 0.91m
F - Wheelbase 3.05m
G - Ground Clearance 0.42m
Platform Capacity 250kg
Drive Speed 5.0km/h
Gradeability 45%(24°)
Axles Oscillation 0.2m
Turning Radius (Inside) 3.14m
Turning Radius (Outside) 6.48m
Turntable Swing 360° continuous
Platform Rotation ±90°
H-Tail Swing 1.022m
Max. Working Slope 4°
Max. Wind Speed 12.5m/s
