Work Height 15.80m
Platform Height 13.80m
Horizontal Outreach 8.30m
Up and Over Height 7.55m
A - Stowed Length 6.57m
B - Stowed Width 2.30m
C - Stowed Height 2.27m
D - Platform Length 1.83m
E - Platform Width 0.76m
F - Wheelbase 2.36m
G - Ground Clearance 0.42m
RECOMMENDED
PRODUCTS
Platform Capacity 300kg
Drive Speed 6.8km/h
Gradeability 45%(24°)
Axles Oscillation 0.1m
Turning Radius (Inside) 2.06m
Turning Radius (Outside) 4.78m
Turntable Swing 355° non-continuous
Platform Rotation ±90°
H-Tail Swing 0
Max. Working Slope -
Max. Wind Speed 12.5m/s
