Work Height 11.55m
Platform Height 9.55m
Horizontal Outreach 6.85m
Up and Over Height 4.6m
A - Stowed Length 5.5m
B - Stowed Width 1.19m
C - Stowed Height 1.98m
D - Platform Length 1.17m
E - Platform Width 0.76m
F - Wheelbase 1.65m
G - Ground Clearance 0.1m
Jib length 1.24m
Transport Length (jib tucked under) 3.95m
Transport Height (jib tucked under) 2.45m
Platform Capacity 230kg
Drive Speed 5km/h
Gradeability 35% (19°)
Axles Oscillation -
Turning Radius (Inside) 1.7m
Turning Radius (Outside) 3.25m
Jib Swing 355° non-continuous
Turntable Swing ±90°
Platform Rotation ±90°
H-Tail Swing 0m
Max. Working Slope -
Max. Wind Speed 12.5m/s
