Work Height 10.00m/7.8m
A - Platform Height-Elevated 8.00m/5.8m
B - Platform Height-Stowed 1.26m
C - Platform Length 2.30m
D - Platform Width 0.81m
Platform Extension 0.91m
E Overall Height (Rails Up) 2.4m
Overall Height (Rails Down) 1.9m
F Overall Length 2.49m
G Overall Width 0.81m
H Wheelbase 1.85m
I Ground Clearance (Stowed) 0.11m
J Ground Clearance (Raised) 0.02m
Platform Capacity 230kg
Capacity on Deck Extension 113kg
Max. Number of Workers 2/1
Drive Speed (Stowed) 4km/h
Drive Speed (Raised) 0.8km/h
Turning Radius (Inside) 0.1m
Turning Radius (Outside) 2.1m
Lifting Motor 24V/3.3KW
Drive Motor 2×0.75KW
Up/Down Time 31s/40s
Gradeability 25%(14°)
Max. Working Slope (Lateral/Vertical) 1.5°/3°
Control Proportional Control
Drive Front Wheels
Brake Front Wheels
Tire ф381mm×127mm
