Work Height 7.8m
A - Platform Height-Elevated 5.8m
B - Platform Height-Stowed 1.05m
C - Platform Length 1.65m
D - Platform Width 0.74m
Platform Extension 0.91m
E - Overall Height (Rails Up) 2.20m
Overall Height (Rails Down) 1.79m
F - Overall Length 1.85m
G - Overall Width 0.81m
H - Wheelbase 1.37m
I - Ground Clearance (Stowed) 0.06m
J - Ground Clearance (Raised) 0.016m
Platform Capacity 230kg
Capacity on Deck Extension 113kg
Max. Number of Workers 2/1
Drive Speed (Stowed) 4km/h
Drive Speed (Raised) 0.8km/h
Turning Radius (Inside) 0.1m
Turning Radius (Outside) 1.6m
Lifting Motor 24V/3.3KW
Drive Motor 2x0.65KW
Up/Down Time 20s/24s
Gradeability 25%(14°)
Max. Working Slope (Lateral/Vertical) 1.5°/3°
Control Proportional Control
Drive Front Wheels
Brake Front Wheels
Tire ф323mm×100mm
