Work Height 10.00m
A - Platform Height-Elevated 8.00m
B - Platform Height-Stowed 1.26m
C - Platform Length 2.30m
D - Platform Width 1.12m
Platform Extension 0.91m
E - Overall Height (Rails Up) 2.4m
Overall Height (Rails Down) 1.87m
F - Overall Length 2.49m
G - Overall Width 1.15m
H Wheelbase 1.85m
I - Ground Clearance (Stowed) 0.11m
J - Ground Clearance (Raised) 0.02m
Platform Capacity 450kg
Capacity on Deck Extension 113kg
Max. Number of Workers Indoor: 2
Outdoor: 1
Drive Speed (Stowed) 3.5km/h
Drive Speed (Raised) 0.8km/h
Turning Radius (Inside) 0.1m
Turning Radius (Outside) 2.2m
Up/Down Drive Motor 24V/4.5KW
Up/Down Time 31s/40s
Gradeability 25%(14°)
Max. Working Slope (Lateral/Vertical) 1.5°/3°
Control Proportional Control
Drive Front Wheels
Brake Rear Wheels
Tire Solid tire
