Work Height 18m
A Platform Height-Elevated 16m
B Platform Height-Stowed 2.03m
C Platform Dimension (Length) 3.98m
D Platform Dimension (Width) 1.83m
Platform Extension 1.3m
Overall Height (Rails Up) 3.16m
E Overall Height (Rails Down) 2.47m
F Overall Length 4.88m
G Overall Width 2.3m
H Wheelbase 2.9m
I Ground Clearance 0.275m
Platform Capacity 680kg
Capacity on Deck Extension 230kg
Drive Height 9m
Max. Number of Workers 4
Drive Speed (Stowed) 6.5km/h
Drive Speed (Raised) 0.5km/h
Turning Radius (Inside) 2.75m
Turining Radius (Outside) 5.8m
Up/Down Time 60/65s
Gradeability 40%（22°）
Max. Working Slope (Lateral/Vertical) 2°/3°
Drive 4WD
Tire 33×12-20/8 Solid Tire
