Work Height 21.38m
Platform Height 19.38m
Horizontal Outreach 12.1m
Up and Over Height 8.25m
A - Stowed Length 8.8m
B - Stowed Width 2.46m
C - Stowed Height 2.52m
D - Platform Length 2.44m
E - Platform Width 2.44m
F - Wheelbase 2.52m
G - Ground Clearance 0.4m
Platform Capacity 250kg/360kg
Drive Speed 6.1km/h
Gradeability 45%
Axles Oscillation 0.20m
Turning Radius (Inside) 2.78m
Turning Radius (Outside) 5.49m
Turntable Swing 360° continuous
Platform Rotation ±90°
H-Tail Swing 0.64m
Max. Working Slope 3°/5°
Max. Wind Speed 12.5m/s
