Work Height 17.8m
Platform Height 15.8m
Horizontal Outreach 9.72m
Up and Over Height 8m
A - Stowed Length 7.7m
B - Stowed Width 2.3m
C - Stowed Height 2.23m
D - Platform Length 1.83m
E - Platform Width 0.76m
F - Wheelbase 2.36m
G - Ground Clearance 0.36m
Platform Capacity 250kg
Drive Speed 5.5km/h
Gradeability 45%(24°)
Axles Oscillation 0.20m
Turning Radius (Inside) 2.06m
Turning Radius (Outside) 4.78m
Turntable Swing 360° non-continuous
Platform Rotation ±90°
H-Tail Swing 0.2m
Max. Working Slope 5°
Max. Wind Speed 12.5m/s
