Work Height 27m
Platform Height 25m
Horizontal Outreach 14.2m
Up and Over Height 12.7m
Below Ground Reach 5.8m
A - Stowed Length (w/ platform） 6.15m
D - Stowed Length (w/o platform) 5.7m
B - Stowed Width 0.89m
C - Stowed Height 2.05m
E - Platform Length 1.4m
F - Platform Width 0.7m
G - Platform Height 1.25m
H - Crawler Size (Length×Width) 1.52m×0.25m
I - Max Length w/ Outrigger Extending (Standard) 4.95m
J - Max Width w/ Outrigger Extending (Standard) 4.48m
K - Max Length w/ Outrigger Extending (Narrow) 6.45m
L - Max Width w/ Outrigger Extending (Narrow) 2.88m
Outrigger Pad Size (Diameter) 0.26m
Approach Angle 15°
Depature Angle 24°
Platform Capacity 230kg（restricted）/120kg（unrestricted）
Drive Speed 2km/h&&
Gradeability 16.7°/30%
Allowable Tilting Angle When Driving 10°/17%
Turntable Swing 400° non-continuous
Platform Rotation ±90°
H-Tail Swing 0m
Max Leveling Angle 16°
Max Wind Speed 12.5m/s
