Main Parameters |
Unit |
Value |
|
Curb weight |
t |
34.66 |
|
Rated payload |
t |
85 |
|
Max. speed |
km/h |
35(MT) / 45(AT) |
|
Max. gradeability |
% |
32 |
|
Min. turning radius |
m |
11 |
|
Axle payload |
t |
35+45+45 |
|
Steering system |
/ |
Fully hydraulic |
|
Tires |
/ |
16.00R25 |
|
Engine model |
/ |
YCK13580-T400 |
|
Emission standard |
/ |
China Non-road Stage III |
|
Engine displacement |
L |
12.939 |
|
Rated power |
kW/rpm |
426 |
|
Max. torque |
N·m/rpm |
2600 N · m/1100~1900 r/min |
|
Transmission model (MT) |
/ |
FAST 8DS260 |
|
Transmission model (AT) |
/ |
FC 6A250 |
|
Capacity |
m³ |
32(Struck) 38(Heaped 2:1) |
