Main Parameters |
Unit |
Value |
|
Curb weight |
t |
34 |
|
Rated payload |
t |
75 |
|
Max. speed |
km/h |
41(MT) / 45.6(AT) |
|
Max. gradeability |
% |
33 |
|
Min. turning radius |
m |
13 |
|
Capacity (struck) |
m³ |
30 |
|
Capacity (heaped 2:1) |
m³ |
34 |
|
Tires |
/ |
16.00R25 |
|
Engine model |
/ |
YCK13580-T400 |
|
Engine displacement |
L |
12.939 |
|
Emission standard |
/ |
China Non-road Stage III |
|
Rated power |
kW |
426 |
|
Max. torque |
N · m/rpm |
2500 N · m/1100~1500 r/min |
|
Transmission (MT) |
/ |
FAST 8DS260 |
|
Transmission (AT) |
/ |
FC6A250 |
|
Steering system |
/ |
Fully hydraulic |
