Rear Wheel 5.00-8-10PR
Front Wheel 6.50-10-10PR
Overall Dimension(L×H×W) 2905 mm×1990 mm×1090 mm
Weight 2990 kg
Rated capacity 1500 kg
Load centre 500 mm
Lifting height 3000 mm
Free lifting height 135 mm
Tilting angle 6°/12°
Turning radius 1850 mm
Front overhang 400 mm
Tread 426 mm
Wheelbase 1250 mm
Fork spread(Min./Max.) 920 mm
Working aisle width with pallet(Ast) 3570 mm
Service weight -
Operating pressure for attachment 111.9 kg/cm²
