Rear Wheel 18×7-8-14PR
Front Wheel 7.00-12-12PR
Overall Dimension(L×H×W) 3279 mm×1995 mm×1150 mm
Weight 3950 kg
Rated capacity 2000 kg
Load centre 500 mm
Lifting height 3000 mm
Free lifting height 145 mm
Tilting angle 6°/12°
Turning radius 2090 mm
Front overhang 475 mm
Tread 454 mm
Wheelbase 1450 mm
Fork spread(Min./Max.) 920 mm
Working aisle width with pallet(Ast) 3885 mm
Service weight -
Operating pressure for attachment 117.3 kg/cm²
